50kW, 100kW, 150kW, 200kW
BESS
AC or DC Coupled
Solar, Grid & DGen Ready

MEGATRON 50 to 200kW Battery Energy Storage Systems have been created to be an install ready and cost effective on-grid, hybrid, off-grid commercial/industrial battery energy storage system.  Each BESS enclosure has a PV inverter making it easy for completing your renewable energy project (excludes MEG 200kW which is AC coupled).  Multiple functionality modes allows simple switching between Grid, PV, or Genset enabling better user control and stability.  All systems have configuration options of 380/400/415 VAC 50/60Hz, 3W+N+PE, 3 phase.

Our commercial and industrial battery systems include Lithium Iron Phosphate (LiFePO4) battery packs connected in high voltage DC configurations.  Battery Systems come with 4000 cycle warranty and up to 100% DOD (Depth of Discharge) @ 1C 25℃.

These DC coupled systems (higher round trip efficiency) offer small to medium sized commercial customers turn key energy storage solutions that are designed for 10+ years of hassle free energy generation and usage.

Offered with a 24 x 7 cloud-based monitoring and operation platform supports multiple mobile and PC devices.  The battery pack, string and ESS are certified by TUV to align with IEC/CE standards.



Download Datasheet

MEGATRON 150kW BESS

150kW BESS
225kWh
PV Ready

Simplified Battery Energy<br>Storage Systems

Simplified Battery Energy
Storage Systems

MEGATRONS 50kW to 200kW Battery Energy Storage Solution is the ideal fit for light to medium commercial applications.  Utilizing Tier 1 LFP battery cells, each commercial BESS is designed for a install friendly plug-and-play commissioning.

Each system is constructed in a environmentally controlled container including fire suppression.  Each complete system offers users a hassle free service life and holds internationally compliant certifications.

wave banner

Common Applications

  • Large Residences
  • Small Business’ & Factories
  • Shopping and Distribution Centers
  • Offices Buildings
  • Schools and Libraries
  • Island communities
  • EV Stations

BESS Benefits

  • Automatic Switching Between ON/Off-Grid
  • PV, Genset & Grid Connect Ready
  • Built in Climate Control & Fire Suppression
  • Small Footprint to Power Ratio
  • Can Integrate with Solar + EV Charging
  • Real Time System Monitoring

50, 100, 150 and 200kW
Battery Energy Storage Systems
Include

Each BESS solution is pre-engineered and manufactured to be ready to install.

Each BESS includes:

  • Battery Racks & Wiring (LFP)
  • BESS Controller with Battery Management System (BMS)
  • High Voltage Units
  • 50 to 200kW Power Conversion System (PCS) (DC/AC)
  • 50 to 100kW PV Inverter (DC/DC) (200kW BESS is AC Coupled)
  • 50 to 200kW STS
  • HVAC System
  • Fire Suppression System
  • Installation Manuals, Certificates, Usage Guide, etc.

MEG-50-to-200-Exploded-View-2023

Inquire Now!

50kW PV + 50kW BESS

50kW PV System
50kW BESS

Solar + Storage<br>Pairing Options

Solar + Storage
Pairing Options

ATLAS Commercial and HERCULES Carport PV systems perfectly pair with MEGATRON battery energy storage systems.

MEGATRON 50kW to 150kW systems can be paired with 50kW to 100kW’s of PV.  Each BESS has either 50kW or 100kW solar inverter integrated into the containerized system.

A solar combiner box is designed in to bring all the PV strings together at the correct DC voltage window.

ATLAS Commercial PV Systems

HERCULES Solar Carport Systems

50 to 150kW
Battery Energy Storage System
Single Line Diagram

MEGATRON 50 to 200kW BESS Single Line Drawing




50

PV System
(kW)

50

PCS
(kW)

75

Battery
(kWh)

100

PV System
(kW)

100

PCS
(kW)

150

Battery
(kWh)

100

PV System
(kW)

150

PCS
(kW)

225

Battery
(kWh)

AC Coupled

PV System
(kW)

200

PCS
(kW)

300

Battery
(kWh)

Sizes are subject to change without notice.
