500kW C&I Battery
Energy Storage System
- DC Coupled, Solar Ready -

MEGATRON 500kW Battery Energy Storage Systems are the largest PV ready (DC Coupled) BESS systems offered in both the 20′ and 40′ containers.  Each BESS is on-grid, hybrid, off-grid ready making it an ideal solution for commercial/industrial customers.  The 20′ systems are designed and shipped with the batteries pre installed utilizing UN 3536 shipping standards however the 40′ container systems are typically not due to weight restrictions.  Each BESS container has a 400kW PV inverter making it easy for completing your renewable energy project.  Multiple functionality modes allows simple switching between Grid, PV, or Genset enabling better user control and stability.   All system systems are offered in either 400VAC or 480VAC 3 phase.

Each commercial and industrial battery energy storage system includes Lithium Iron Phosphate (LiFePO4) battery packs connected in high voltage DC configurations.  Battery Systems come with 5000 cycle warranty and up to 80% DOD (Depth of Discharge) @ 1C 25℃.

These DC coupled systems (higher round trip efficiency) offer large residential and light commercial customers turn key energy storage solutions that are designed for 10+ years of hassle free energy generation and usage (

Offered with a 24 x 7 cloud-based monitoring and operation platform supports Mysql database and multiple mobile and PC devices.  The battery pack, string and ESS are certified by TUV to align with IEC/UL standards of UL 9540A, UL 1973, IEC 62619 etc.



Inquire Now!

MEGATRON 500kW BESS

500kW BESS
552kWh
20 Foot Container
PV Ready

500kW Battery Energy<br>Storage System

500kW Battery Energy
Storage System

MEGATRONS 500kW Battery Energy Storage Solution is the ideal fit for commercial applications.  Utilizing Tier 1 LFP battery cells, each commercial BESS is designed for a install friendly plug-and-play commissioning.

Each system is constructed in a environmentally controlled container including fire suppression.  Each complete system offers users a hassle free 10+ year service life and hold internationally compliant certifications.

Common Applications

  • Microgrid Projects
  • Business’s & Factories
  • Shopping & Distribution Centers
  • Offices Buildings
  • Schools and Libraries
  • Island communities
  • EV Stations

BESS Benefits

  • Pre-Installed System from Factory
  • Simplified Installation
  • PV & Genset Ready to Connect
  • Demand Charge Reduction
  • Energy Independence (w/PV)
  • Peak Load Shifting
  • Full Back Up Power (Auto Switching)

500kW
Battery Energy Storage Systems
Include

Each 500kW BESS solution is pre-engineered and manufactured to be ready to install.

Each BESS includes:

  • Battery Racks & Wiring (LFP)
  • BESS Controller with Battery Management System
  • High Voltage Units (BMS)
  • 500kW Power Conversion System (PCS) (DC/AC)
  • 400kW DC/DC Converter
  • 500kW Transformer
  • 800kW STS (excludes N/A systems)
  • 20 & 40 foot Storage Container
  • HVAC System
  • Fire Suppression System
  • Installation Manuals, Certificates, Usage Guide, etc.

BESS Exploded view

500kW
Battery Energy Storage System
Single Line Diagram

500kW Single Line Drawing for Battery Energy Storage System

500kW
Battery Energy Storage System
Sizes

500+

PV System
(kW)

500

Inverter
(kW)

552

Battery
(kWh)

500+

PV System
(kW)

500

Inverter
(kW)

1104

Battery
(kWh)

500+

PV System
(kW)

500

Inverter
(kW)

1656

Battery
(kWh)

500+

PV System
(kW)

500

Inverter
(kW)

2208

Battery
(kWh)

Sizes are subject to change without notice.
